Y-19
Details:SIHF
Description: 2 core Silicone insulation and jacket cable
Conductor: tinned copper
Construction: 9/0.18 2*0.5mm2
Insulation: Silicone Rubber
Jacket: Silicone Rubber
O.D. 6mm
Silicone rubber cable look at the name of this product can see that it is closely related to silicone rubber, silicone rubber cable its insulator material is rubber, its conductor is tinned copper, silver plated copper, nickel plated copper stranded wire or bare copper wire, this product is widely used in petroleum, instruments, motors, car connection lines.
Silicone rubber cable it has cold resistance and heat resistance and a certain degree of softness and other holding points, so the sales of this cable in the market is gradually rising, but a product must have its advantages and disadvantages, today Tripod to popularize the advantages and disadvantages of silicone rubber cable.
Silicone rubber cable has the advantages of excellent high and low temperature performance, excellent electrical insulation performance, high voltage resistance, aging resistance, long service life, and soft and easy to install. This product has the advantages of good softness, water resistance and pressure resistance.
The disadvantages of silicone rubber cable: silicone material itself is not wear-resistant, not corrosion resistant, not oil resistant: the strength of the insulation material itself is low, there are sharp or sharp metal in the use environment, insulation is very easy to scratch or puncture, so it is recommended to lay fixed. Our company produces high temperature wire and cable for 18 years, has a strong production research and development team, rich experience in production research and development, long-term cooperation with cable research institute, National Quality supervision and inspection center and other research institutes and universities, strong technical strength, and strive to provide customers with high quality products and services, protect the high temperature environment electricity safety.
PRODUCT SPECIFICATION
| AWG | No. of Cores | Conductor cross section
mm^2 | Nominal OD
mm | Copper weight
kg/km | Gross Weight
kg/km |
| 20 | 2 | 0.25 | 8.7 | 55.5 | 101 |
| 20 | 3 | 0.25 | 8.9 | 60.8 | 118 |
| 20 | 4 | 0.25 | 9.4 | 66.5 | 131 |
| 20 | 5 | 0.25 | 10 | 81.6 | 153 |
| 20 | 7 | 0.25 | 10.5 | 92.2 | 173 |
| 20 | 10 | 0.25 | 13.1 | 124 | 242 |
| 20 | 12 | 0.25 | 13.4 | 134.4 | 263 |
| 20 | 16 | 0.25 | 14.6 | 170.2 | 326 |
| 20 | 18 | 0.25 | 15.1 | 181 | 351 |
| 20 | 25 | 0.25 | 19.4 | 230.1 | 348 |
| 18 | 2 | 0.75 | 9.2 | 61.4 | 124 |
| 18 | 3 | 0.75 | 9.5 | 69.1 | 136 |
| 18 | 4 | 0.75 | 10.1 | 86.7 | 159 |
| 18 | 5 | 0.75 | 10.8 | 95.2 | 180 |
| 18 | 7 | 0.75 | 11.6 | 113.3 | 212 |
| 18 | 10 | 0.75 | 14.4 | 165.2 | 306 |
| 18 | 12 | 0.75 | 14.7 | 180.3 | 333 |
| 18 | 16 | 0.75 | 16.5 | 212.2 | 418 |
| 18 | 18 | 0.75 | 17.3 | 282.1 | 453 |
| 18 | 25 | 0.75 | 22.1 | 297.4 | 468 |
| 17 | 2 | 1 | 9.5 | 66.7 | 132 |
| 17 | 3 | 1 | 9.7 | 86.2 | 153 |
| 17 | 4 | 1 | 10.4 | 96.8 | 173 |
| 17 | 5 | 1 | 11.3 | 108.3 | 202 |
| 17 | 7 | 1 | 12 | 141.2 | 243 |
| 17 | 10 | 1 | 14.9 | 190 | 238 |
| 17 | 12 | 1 | 15.2 | 209.8 | 371 |
| 17 | 16 | 1 | 17 | 251.8 | 468 |
| 17 | 18 | 1 | 17.8 | 297.4 | 526 |
| 17 | 25 | 1 | 23 | 329 | 559 |
| 16 | 2 | 1.5 | 10.7 | 87.7 | 172 |
| 16 | 3 | 1.5 | 11.2 | 103.5 | 198 |
| 16 | 4 | 1.5 | 11.8 | 131.7 | 235 |
| 16 | 5 | 1.5 | 13.3 | 148.5 | 281 |
| 16 | 7 | 1.5 | 14.3 | 193.4 | 345 |
| 16 | 10 | 1.5 | 17.7 | 268.5 | 482 |
| 16 | 12 | 1.5 | 18 | 298.4 | 531 |
| 16 | 16 | 1.5 | 20.1 | 362.3 | 662 |
| 16 | 18 | 1.5 | 20.9 | 394 | 720 |
| 16 | 25 | 1.5 | 24.1 | 488.2 | 791 |
| 14 | 2 | 2.5 | 12.1 | 122.3 | 230 |
| 14 | 3 | 2.5 | 12.9 | 147.7 | 275 |
| 14 | 4 | 2.5 | 14.2 | 188.6 | 340 |
| 14 | 5 | 2.5 | 15.3 | 214.9 | 394 |
| 14 | 7 | 2.5 | 16.9 | 265.7 | 488 |
| 12 | 4 | 4 | 17.1 | 294 | 520 |
| 12 | 5 | 4 | 19.4 | 374 | 653 |
| 10 | 4 | 6 | 18.8 | 449 | 781 |
| 10 | 5 | 6 | 21.2 | 563 | 982 |
| 8 | 4 | 10 | 25.7 | 759 | 1294 |
| 6 | 4 | 16 | 28.4 | 1180 | 1988 |
| 4 | 4 | 25 | 35 | 1810 | 2995 |
